netBooter DU Series PDU

Secure Remote Power Control for Simple Setups

The netBooter DU Series delivers dependable remote outlet control with HTTPS access, simple configuration, and essential automation—ideal for small deployments and uncomplicated power management.

Request a Demo Kit Request a Quote Datasheet

Key Features

Individual Outlet Control

Remotely power cycle, enable, or disable each power outlet independently, giving you precise control over every connected device.

Auto-Detect and Recover Unresponsive Equipment

Monitor remote devices with AutoPing. Automatically power cycle an outlet when devices fail to respond to pings.

Manage Devices Securely via HTTPS

Access PDUs directly through a HTTPS web interface with TLS v1.2 encryption

Serial Port Access via USB or DB9

Access PDUs locally via serial port, with built in USB (FTDI based) or DB9 RS-232 interfaces

Inlet Current Monitoring

Measure real-time inlet current to prevent overloads and ensure safe, reliable power distribution

Monitor Temperature

Measure and monitor environmental temperature. with an optional TS-0300 temperature probe.

Applications

SMB IT Environments

Small network closets
Routers, switches, LTE backup devices
Basic RMS current and temp monitoring

SMB Retail

POS and network gear in stores or QSRs
Multi-device power control
Cost-sensitive remote management setups

Light Industrial

Assembly lines and equipment stations
QA and test benches
Thermal monitoring for enclosed devices

Labs & Engineering

Engineering benches
Simple automated cycling
Remote control for test setups

Technical Specifications

Input

IEC 320 C14 or IEC 320 C20

Input Voltage Options

100-120V, 60Hz or
100-240V, 50-60Hz

Max Input Current

13A (10.4A derated)
15A (12A derated)
20A (16A derated)

Phase

Single-Phase

Input Measurement

Current RMS (A) Measurement

Output

Outlet Voltage Options

100-120V or 100-240V

Outlet Receptable Options

NEMA 5-15R or IEC 320 C13

Outlet Count Options

2, 5, 8, 10, 16, 20

Overload Protection

None

Outlet Measurement

None

Outlet Switching

Individual outlet switching

Access, Communication, and Security

Networking Protocols

HTTP(S), Telnet, SMTP, SNMPv1,2, DHCP, Ping, NTP, IPv4

Network Interface

10/100 BaseT Ethernet (RJ45)

Encryption

HTTPS (TLS v1.2)
_{Note - SSH is not available}

User Access Management

Local user accounts

Serial Communication Options

DB9 RS-232 or USB

Front Panel

LED indicators for individual outlet on/off status

1 LED indicator for PDU On/ Off status

1 LED indicator for Network status

1 7-digit LED display for inlet current

Sensors

Sensor port for Temperature measurement via TS-0300 Probe

Physical

Form Factor Options

Compact (2 outlet)
1U Strip (5 outlet)
1U (8 outlet)
2U (16 outlet)
0U (10 or 20 outlet)

Dimensions

Compact: 6.2 x 5.4 x 1.75 1U
1U Strip: 19” x 2.125” x 1.75”
1U: 19" x 6.25" x 1.75"
2U: 19" x 6.25" x 3.5"
0U (10 outlet): 31.8" x 2.8" x 1.75"
0U (20 outlet): 53.2" x 2.8" x 1.75"

Operating Temperature

-5C to 60 C

Storage Temperature

-25C to 65 C

Humidity

5-95%, non-condensing

Simple, Reliable Power Distribution

Secure Remote Outlet Control

Turn outlets on or off individually to remotely reboot devices or restore unresponsive equipment without needing to be onsite. Reduce downtime, resolve lockups quickly, and eliminate the need to dispatch personnel for simple power resets.

Auto-Detect and Recover Unresponsive Equipment

Monitor remote devices with AutoPing. Automatically take action when an outlet when a device stops responding to pings. Send alerts via email or perform outlet reboots to restore functionality.

Model Configurations

netBooter DU Series Compact Model SKUs

SKU

Form Factor

Outlets

Inlet Plug

Outlet Type(s)

Voltage

Max Amps

Serial Port

NP-0201DU-USB

Compact

IEC 320 C14

NEMA 5-15R

100-120V

13A (10.4A)

USB

NP-0201DU-DB9

Compact

IEC 320 C14

NEMA 5-15R

100-120V

13A (10.4A)

DB9

NP-0201DUH-DB9

Compact

IEC 320 C14

IEC 320 C13

100-240V

13A (10.4A)

DB9

netBooter DU Series 1U Model SKUs

SKU

Form Factor

Outlets

Inlet Plug

Outlet Type(s)

Voltage

Max Amps

Serial Port

NP-0501DU-USB

1U Strip

IEC 320 C14

NEMA 5-15R

100-120V

15A (12A)

USB

NP-0501DU-DB9

1U Strip

IEC 320 C14

NEMA 5-15R

100-120V

15A (12A)

DB9

NP-0801DU-USB

IEC 320 C14

NEMA 5-15R

100-120V

15A (12A)

USB

NP-0801DU-DB9

IEC 320 C14

NEMA 5-15R

100-120V

15A (12A)

DB9

NP-0801DUH-USB

IEC 320 C14

IEC 320 C13

100-240V

15A (12A)

USB

NP-0801DU-G2-USB

(2x) IEC 320 C14

NEMA 5-15R

100-120V

2x 15A (12A)

USB

NP-0801DU-G2-DB9

(2x) IEC 320 C14

NEMA 5-15R

100-120V

2x 15A (12A)

DB9

NP-0801DUH-G2-USB

(2x) IEC 320 C14

IEC 320 C13

100-240V

2x 15A (12A)

USB

NP-0801DUH-G2-DB9

(2x) IEC 320 C14

IEC 320 C13

100-240V

2x 15A (12A)

DB9

netBooter DU Series 2U Model SKUs

SKU

Form Factor

Outlets

Inlet Plug

Outlet Type(s)

Voltage

Max Amps

Serial Port

NP-1601DU-USB

(2x) IEC 320 C14

NEMA 5-15R

100-120V

2x 15A (12A)

USB

NP-1601DU-A-USB

(1x) IEC 320 C20

NEMA 5-15R

100-120V

20A (16A)

USB

NP-1601DUH-DB9

(2x) IEC 320 C14

IEC 320 C13

100-240V

2x 15A (12A)

DB9

netBooter DU Series 0U Model SKUs

SKU

Form Factor

Outlets

Inlet Plug

Outlet Type(s)

Voltage

Max Amps

Serial Port

NP-10DU-USB

IEC 320 C20

NEMA 5-15R

100-120V

20A (16A)

USB

NP-10DU-DB9

IEC 320 C20

NEMA 5-15R

100-120V

20A (16A)

DB9

NP-10DUH-USB

IEC 320 C20

IEC 320 C13

100-240V

20A (16A)

USB

NPB-20DU-USB

IEC 320 C20

NEMA 5-15R

100-120V

20A (16A)

USB

NPB-20DUH-DB9

IEC 320 C20

IEC 320 C13

100-240V

20A (16A)

DB9

Looking for a different configuration? Additional options and customizations are available—reach out to our sales team.

Certified Excellence

Synaccess PDUs meet the highest safety and quality standards, ensuring peace of mind for your business

UL/CSA Certified

Adhering to strict North American safety standards. UL/CSA 62368-1 certified.

CE Approved

CE Approved for Global Conformity

RoHS Compliant

Adhering to strict North American safety standards. UL/CSA 62368-1 certified.

TAA Compliant

Proudly engineered and supported in the USA
